Cambium Network Xirrus™ XV2-2 Access Points
Dual radio Wi-Fi 6 AP, 2x2


Cambium Networks Xirrus XV2-2 Access Points

Cambium Networks Products
cnPilotXirrus™ XV2-2 Access Points
Indoor Dual Radio Wi-Fi 6 2x2 WLAN AP, 2.5GBE
#XV2-2X00A00-US
Our Price: $586.00
Outdoor Dual radio WiFi 6 AP Omni 2x2, 2.5GbE, 30V/48V out, BLE. US
#XV2-2T0XA00
Our Price: $684.00

Click here to jump to more pricing!

Overview:

Upgrade 802.11ac Wi-Fi network with the latest Wi-Fi 6 technology. Ideal for SME, hotels, retail and education looking for a low risk upgrade to the next generation technology to support new mobile devices and IOT.

XV2-2 At a Glance

  • 802.11a/b/g/n/ac, ax wave 2
  • 5GHz (2x2), 2.4GHz (2x2)
  • 1 2.5GbE RJ45 interface
  • 802.3at PoE PD

cnPilotXirrus™ XMS

  • Intuitive Drag Drop interface
  • Network and location analytics
  • EasyPass™ , Command Center, AVC

cnMaestro™

  • Broadband PtP-Ethernet-WiFi
  • Help desk troubleshooting tools
  • Cloud managed Guest Access

Features & Benefits:

Investment protection with Wi-Fi 6

Cambium Networks XV2-2 enables managed service providers and IT administrators to upgrade the enterprise Wi-Fi network for the next generation of devices without breaking the bank today. Managed service providers often provide a technology upgrade as part of the service, and the XV2-2 is an ideal fit for managed services in small to medium enterprise, primary and secondary schools, retail and hospitality.

The XV2-2 includes automatic RF management to optimize the wireless performance and mitigate interference from other access points within the enterprise or from neighbor wireless networks. MESH, auto MESH, zero touch provisioning and integrated help desk tools further simply deployment.

XV2-2 is part of the cnPilotXirrus™ series X portfolio designed to operate with either the XMS management system or cnMaestro™

cnPilotXirrus™ XMS Cloud or XMS Enterprise VM

XMS automatic provisioning and a host of applications to enhance network management in enterprise, education and large venues. XV2-2 support EasyPass™ for BYOD policy access, L7 application visibility and control, and Command Center drag n drop managed service provider application.

cnMaestro™ Single Pane of Glass

Adopt, provision, manage and report network deployments with the Cambium Networks cnMaestro™ from the Cloud or on premises VM. cnMaestro features zero touch provisioning for broadband point to point, Ethernet switching, residential and enterprise Wi Fi access points..

Specifications:

802.11 CAPABILITIES
802.11a/b/g/n/ac/ax 802.11ax wave 2, up to 2x2:2:2, MU-OFDMA, MU-MIMO, TWT, MIMO, VHT MCS rates, 16/64/256/1024-QAM, HT20/40/80/80+80 MHz, Transmit Beam steering, Airtime Fairness, AMSDU, AMPDU, RIFS, STBC, LDPC, MIMO Power Save, MRC, BPSK, QPSK, CCK, DSSS, OFDM. IEEE 802.11d/e/h/ i /k/r/u/v/w

ACCESS POINT SPECIFICATIONS

US-FCC
2400—2484 MHz, 5150—5250 MHz, 5725—5850 MHz
ROW (individual country limits may apply)
2400—2500 MHz, 5150—5850 MHz
Note: US FCC, IC FCC, EU DFS channels not supported in first release
SSID SECURITY WPA2 (802.11i), WPA2 Enterprise (802.1x/EAP), WPA PSK, Open
MAX PHY RATE 2.4 GHz radio: 595 Mbps
5 GHz radio: 2475 Mbps
PORTS One IEEE 2.5 Gigabit Ethernet auto sensing
ANTENNA 5dBi (2.4GHz) 5dBi (5GHz), Omni 2 x 2.4GHz, 2 x 5GHz
MAX EIRP1 2.4 GHz: 30 dBm
5 GHz: 30 dBm
POWER 802.3at Powered Device, max 30w
PHYSICAL ENVIRONMENTAL 200mm x 200mm x 50mm, 800g
Kensington lock slot
Multi-color status LEDs
0C - +50C ambient op temp
-20C - +70C storage temperature
95% RH non-condensing
CERTIFICATIONS WiFi Alliance 80211a/b/g/n/ac, PP2.0 FCC, ETSI, CE, EN 60601-1-2, IEC60950
EIRP may be limited by individual country regulation



WLAN AND NETWORK SPECIFICATIONS

CONTROLLER MODE Controller-less standalone
AutoPilot heterogeneous network
Cloud managed
cnMaestro or VM
Cloud managed XMS or VM
WLAN 512 clients, 16 SSIDs
WPA-TKIP, WPA2 AES, 802.1x
802.11w PMF
CAPTIVE PORTAL Hosted on cnMaestro Controller
On-AP hosted guest portal
Redirect to HTTP/RADIUS
Server DNS logging
AUTHENTICATION ENCRYPTION Hotspot 2.0/ Passpoint 2.0
802.1x EAP-SIM/AKA, EAP-PEAP, EAP-TTLS, EAP-TLS, MAC authentication to local database or external RADIUS
ACCOUNTING RADIUS accounting, multiple AAA
SCHEDULED WLAN On/off by day, week, time of day
GUEST ACCESS EasyPass guest self-registration, guest Ambassador, ePSK , Vouchers, Rate Limit, Splash page hosted on AP or cnMaestro Client isolation per SSID, per network
DATA LIMIT Client rate limit per SSID
SUBSCRIBER QOS WMM
FAST ROAMING 802.11r, OKC, Enhanced roaming
MESH Multi-hop, either band
CHANNEL SELECTION Multi-modal channel selection with AutoChannel , AutoBand (XMS) and autotune ( cnMaestro ). Granular control of off channel scan and channel selection
RF MANAGEMENT Multi-Modal RF optimization supporting AutoCell (XMS) and AutoRF (cnMaestro) performed in the intelligent edge AP. Out of band RF spectrum analysis, radio self test network assurance (XMS), RF monitor with chn /noise/interference
Network NAT, NAT logging firewall, DHCP server L2, L3 or DNS based access control VLAN Pooling, RADIUS attribute VID VLAN per SSID per user
BAND STEER LOAD BALANCE Yes
TUNNEL L2TP, L2oGRE, PPPoE
NETWORK AND RF MANAGEMENT TOOLS wired and wireles remote packet capture, auto logging, ZapD performance tool, rogue AP detection
SERVICES NTP, Syslog, SNMP traps, DNS proxy, auto off on WAN failure
API RESTful management and statistics API Presence location APIs
Pre-release data subject to change

Pricing Notes:

Cambium Networks Products
cnPilotXirrus™ XV2-2 Access Points
Indoor Dual Radio Wi-Fi 6 2x2 WLAN AP, 2.5GBE
#XV2-2X00A00-US
Our Price: $586.00
Outdoor Dual radio WiFi 6 AP Omni 2x2, 2.5GbE, 30V/48V out, BLE. US
#XV2-2T0XA00
Our Price: $684.00
XMS Subscriptions
XMS-Cloud 1 year subscription: 2-radio AP including Cambium Care Advanced Support
#XMSC-SUB-2R-1
Our Price: $90.00
XMS-Cloud 3 year subscription: 2-radio AP including Cambium Care Advanced Support
#XMSC-SUB-2R-3
Our Price: $180.00
XMS-Cloud 5 year subscription: 2-radio AP including Cambium Care Advanced Support
#XMSC-SUB-2R-5
Our Price: $270.00
XMS Support
Cambium Care Advanced Support 1 year subscription: one XV2-2 Wireless AP
#CCADV-SUB-XV2-2-1
Get a Quote!
Cambium Care Advanced Support 3 year subscription: one XV2-2 Wireless AP
#CCADV-SUB-XV2-2-3
Get a Quote!
Cambium Care Advanced Support 5 year subscription: one XV2-2 Wireless AP
#CCADV-SUB-XV2-2-5
Get a Quote!
Cambium Care Pro Support 1 year subscription: one XV2-2 Wireless AP
#CCPRO-SUB-XV2-2-1
Get a Quote!
Cambium Care Pro Support 3 year subscription: one XV2-2 Wireless AP
#CCPRO-SUB-XV2-2-3
Get a Quote!
Cambium Care Pro Support 5 year subscription: one XV2-2 Wireless AP
#CCPRO-SUB-XV2-2-5
Get a Quote!
